Y.S.TECH Fans WV216062HBL-9A2
Y.S.TECH WV216062HBL-9A2 Φ160mm F160 Series EC Forward centrifugal Fan
- SKU
- YHF-1673
There is no price at present, please contact us.
More Information
| Brand | Y.S.TECH |
|---|---|
| Model Number | WV216062HBL-9A2 |
| Type | EC Forward centrifugal Fan |
| Series | F160 |
| Frame Size | Φ160mm |
| Bearing Type | 2Ball |
| Voltage | 230 VAC |
| Current | 1.74 A |
| Speed | 2150 RPM |
| Power | 195 W |
| Air Flow | 405 CFM |
| Static Pressure | 94.996 mmH₂O |
| Noise | 60.9 dBA |
| Expected life | 50000 Hour at 40ºC L10 |
| Operating Temperature | -25~60 ºC |
| Housing Material | Impeller: Hot-dip galvanized sheet steel;Electronics housing: Die-casting aluminum;Motor shell: Steel, electro deposited black |
| Insulation class | B |
