SERVO Fans PA47B3
Servo PA47B3 Ф172x51mm PA Series AC Axial Fans
- SKU
- SOF-110
There is no price at present, please contact us.
More Information
| Brand | Servo |
|---|---|
| Model Number | PA47B3 |
| Type | AC Axial Fans |
| Series | PA |
| Frame Size | Ф172x51mm |
| Bearing Type | Double-sided shielded ball bearing |
| Voltage | 100-120 V |
| Current | 300/270 mA |
| Speed | 2850/3400 RPM |
| Power | 33/32 W |
| Air Flow | 194/229 CFM |
| Static Pressure | 0.61/0.75 InH₂O |
| Noise | 46/50 dBA |
| Operating Temperature | -20~+60ºC |
| Frequency | 50/60 Hz |
| Housing Material | Venturi: Aluminum alloy die casting;Propeller: ABS and PBT synthetic resins;Capacitor cover: Glass fiber reinforced polycarbonate resin;Capacitor: MF capacitor |
