SERVO Fans CU48F3
Servo CU48F3 120x25mm CU Series AC Axial Fans
- SKU
- SOF-075
There is no price at present, please contact us.
More Information
| Brand | Servo |
|---|---|
| Model Number | CU48F3 |
| Type | AC Axial Fans |
| Series | CU |
| Frame Size | 120x25mm |
| Bearing Type | Double-sided shielded ball bearing |
| Voltage | 200-240 V |
| Current | 80/60 mA |
| Speed | 1500/1900 RPM |
| Power | 14/10.5 W |
| Air Flow | 42/49 CFM |
| Static Pressure | 0.07/0.1 InH₂O |
| Noise | 27/34 dBA |
| Operating Temperature | -20~+60ºC |
| Frequency | 50/60 Hz |
| Housing Material | Venturi: Aluminum alloy die casting;Propeller: Glass fiber reinforced polycarbonate resin |
