ORIX Fans MU1225M-51
ORIX MU1225M-51 119x25mm MU1225 Series AC Axial Flow Fans
- SKU
- OXF-018
There is no price at present, please contact us.
More Information
| Brand | ORIX |
|---|---|
| Model Number | MU1225M-51 |
| Type | AC Axial Flow Fans |
| Series | MU1225 |
| Frame Size | 119x25mm |
| Bearing Type | Ball |
| Voltage | Single-Phase220/230 VAC |
| Current | 0.07 A |
| Speed | 2250/2600 RPM |
| Power | 10.0/12.0/9.5 W |
| Air Flow | 1.4/1.7 m³/min |
| Static Pressure | 32/31 Pa |
| Noise | 33/37 dBA |
| Approval Agency | UL,CSA,JET,EN,CE |
| Operating Temperature | -10ºC ~ 60ºC(85% or less noncondensing) |
| Frequency | 50/60 Hz |
| Housing Material | Frame: Die cast aluminum;Blades: Polycarbonate (Flammability classification V-0) |
