NMB Fans 08025SS-24N-AL-D0
More Information
| Brand | NMB |
|---|---|
| Model Number | 08025SS-24N-AL-D0 |
| Type | DC Axial Fans |
| Series | 08025SS |
| Frame Size | 80x80x25mm |
| Bearing Type | Sleeve |
| Voltage | 24 VDC |
| Current | 0.090A |
| Speed | 3100 RPM |
| Power | 2.16 W |
| Air Flow | 41.7 CFM (1.17m³/min) |
| Static Pressure | 0.151 InH₂O (37.5 Pa) |
| Noise | 30 dBA |
| Expected life | 50000 Hours at 40°C |
| Terminals | 3 Wire Leads |
| Operating Temperature | -10 ~ 60ºC |
| Housing Material | Frame:Plastic;Blade:Plastic |
