NMB Fans 05015SS-24R-WL-D0
More Information
| Brand | NMB |
|---|---|
| Model Number | 05015SS-24R-WL-D0 |
| Type | DC Axial Fans |
| Series | 05015SS |
| Frame Size | 50x50x15mm |
| Bearing Type | Sleeve |
| Voltage | 24 VDC |
| Current | 0.090A |
| Speed | 6550 RPM |
| Power | 2.16 W |
| Air Flow | 15.0 CFM (0.420m³/min) |
| Static Pressure | 0.205 InH₂O (51.2 Pa) |
| Noise | 35.5 dBA |
| Expected life | 40000 Hours at 40°C |
| Terminals | 3 Wire Leads |
| Operating Temperature | -10 ~ 70ºC |
| Housing Material | Frame:Plastic;Blade:Plastic |
