NMB Fans 04010SS-24M-AL-00
More Information
| Brand | NMB |
|---|---|
| Model Number | 04010SS-24M-AL-00 |
| Type | DC Axial Fans |
| Series | 04010SS |
| Frame Size | 40x40x10mm |
| Bearing Type | Sleeve |
| Voltage | 24 VDC |
| Current | 0.029A |
| Speed | 6500 RPM |
| Power | 0.7 W |
| Air Flow | 5.7 CFM (0.160m³/min) |
| Static Pressure | 0.149 InH₂O (37.1 Pa) |
| Noise | 24 dBA |
| Expected life | 30000 Hours at 40°C |
| Terminals | 3 Wire Leads |
| Operating Temperature | -10 ~ 70ºC |
| Housing Material | Frame:Plastic;Blade:Plastic |
