IKURA Fans UP92BL10
IKURA UP92BL10 92x25mm P92BL Series AC Resin-Blade Axial Fans
- SKU
- IAF-1201
There is no price at present, please contact us.
More Information
| Brand | IKURA |
|---|---|
| Model Number | UP92BL10 |
| Type | AC Resin-Blade Axial Fans |
| Series | P92BL |
| Frame Size | 92x25mm |
| Bearing Type | 2Ball |
| Voltage | 100 VAC |
| Speed | 1800/2000 RPM |
| Power | 7/6 W |
| Air Flow | 0.7/0.8 m³/min |
| Static Pressure | 22.5/26.4 Pa |
| Noise | 29/31 dBA |
| Approval Agency | UL |
| Operating Temperature | -30～+70ºC/RH20～85% |
| Frequency | 50/60 Hz |
| Housing Material | Standard: Aluminum die-cast unpainted (frame), black synthetic resin (blades) Special:Aluminum die-cast black painted (frame), black synthetic resin (blades) |
