Overview
IKURA AC Resin-Blade Axial Fans P12DH Series UP12DH23
- Mfr. No:UP12DH23
- Brand:IKURA
- Product type:
- Datasheet:
| Brand |
IKURA |
| Type |
AC Resin-Blade Axial Fans |
| Series |
P12DH |
| Frame Size |
120x38mm |
| Bearing Type |
2Ball |
| Voltage |
230 VAC |
| Speed |
2150/2350 RPM |
| Power |
15/14 W |
| Air Flow |
2.2/2.4 m³/min |
| Static Pressure |
49/49 Pa |
| Noise |
37/39 dBA |
| Approval Agency |
UL |
| Operating Temperature |
-30～+70ºC/RH20～85% |
| Frequency |
50/60 Hz |
| Housing Material |
Standard: Aluminum die-cast unpainted (frame), black synthetic resin (blades) Special:Aluminum die-cast black painted (frame), black synthetic resin (blades) |
