Overview
IKURA AC Resin-Blade Axial Fans P80DS Series P80DS22
- Mfr. No:P80DS22
- Brand:IKURA
- Product type:
- Datasheet:
| Brand |
IKURA |
| Product Type |
Standard type |
| Type |
AC Resin-Blade Axial Fans |
| Series |
P80DS |
| Frame Size |
80x38mm |
| Bearing Type |
2Ball |
| Voltage |
220 VAC |
| Speed |
2650/3100 RPM |
| Power |
10/9 W |
| Air Flow |
0.8/0.95 m³/min |
| Static Pressure |
41.1/58.8 Pa |
| Noise |
32/36 dBA |
| Operating Temperature |
-10～+70ºC/RH35～85% |
| Frequency |
50/60 Hz |
| Housing Material |
Standard: Aluminum die-cast unpainted (frame), black synthetic resin (blades) Special:Aluminum die-cast black painted (frame), black synthetic resin (blades) |
