Delta Fan QFR0824SHP6
More Information
| Brand | Delta |
|---|---|
| Model Number | QFR0824SHP6 |
| Type | DC Fans |
| Series | QFR |
| Frame Size | Square-80mmLx80mmHx25.00mm |
| Bearing Type | Ball |
| Voltage | 24 VDC |
| Current | 0.150A |
| Speed | 4300 RPM |
| Power | 3.6 W |
| Air Flow | 50.3 CFM (1.41m³/min) |
| Static Pressure | 0.318 InH₂O (79.2 Pa) |
| Noise | 44.2 dBA |
| Approval Agency | CE, cURus, VDE |
| Expected life | 70000 Hours at 40°C |
| Terminals | 4 Wire Leads |
| IP rating | IP68 - Dust Tight, Waterproof |
| Operating Temperature | 14 ~ 158°F (-10 ~ 70ºC) |
| Housing Material | Frame:Plastic;Blade:Plastic |
