Delta Fan AFB0824HH-T500
More Information
| Brand | Delta |
|---|---|
| Model Number | AFB0824HH-T500 |
| Type | Tubeaxial |
| Series | AFB Series |
| Frame Size | Square-80mm Lx80mm H |
| Bearing Type | Ball |
| Voltage | 24 VDC |
| Speed | 3250 RPM |
| Power | 2.16 W |
| Air Flow | 37.4 CFM (1.05m³/min) |
| Static Pressure | 0.181InH₂O(45.1Pa) |
| Noise | 34.0dBA |
| Approval Agency | CE, CSA, UL, VDE |
| Terminals | 2 Wire Leads |
| IP rating | IP55 - Dust Protected, Water Resistant |
| Operating Temperature | -10~+70ºC |
