NMB Blowers 07520GS-24N-AL-00
NMB 07520GS-24N-AL-00 75x75x20mm 07520GS Series DC Blowers
- SKU
- NBB-094
There is no price at present, please contact us.
More Information
| Brand | NMB |
|---|---|
| Model Number | 07520GS-24N-AL-00 |
| Type | DC Blowers |
| Series | 07520GS |
| Frame Size | 75x75x20mm |
| Bearing Type | Sleeve |
| Voltage | 24 V |
| Current | 0.11 A |
| Power | 2.64 W |
| Speed | 3700 RPM |
| Air Flow | 8.1 CFM |
| Static Pressure | 0.84 InH₂O |
| Noise | 36 dBA |
| Housing Material | Casing:Plastic(Black)UL94V-0;Impeller:Plastic (Black)UL94V-0 |
| Expected life | 40ºC 40,000 Hours |
| Terminals | UL1061, AWG26, +Red, -Black |
| Operating Temperature | -10ºC~+60ºC |
