NMB Fans 12038VA-12Q-EAE-0
NMB 12038VA-12Q-EAE-0 120x38mm 12038VA （E-Type） Series DC Axial Fans
- SKU
- NBF-1652
There is no price at present, please contact us.
More Information
| Brand | NMB |
|---|---|
| Model Number | 12038VA-12Q-EAE-0 |
| Type | DC Axial Fans |
| Series | 12038VA （E-Type） |
| Frame Size | 120x38mm |
| Bearing Type | Ball |
| Voltage | 12 V |
| Current | 2.25 A |
| Speed | 5700 RPM |
| Power | 27 W |
| Air Flow | 215.9 CFM |
| Static Pressure | 1.15 InH?O |
| Noise | 63 dBA |
| Expected life | 60oC 40,000 Hours |
| Terminals | UL10368, AWG24, +Red, -Black or UL3443, AWG24, +Red, -Black |
| Operating Temperature | -10oC~+70oC |
| Housing Material | Casing : Plastic (Black)UL94V-0；Impeller : Plastic (Black)UL94V-0 |
