NMB Fans 09225VA-24Q-EA-00
NMB 09225VA-24Q-EA-00 92x25mm 09225VA/3610VL Series DC Axial Fans
- SKU
- NBF-1641
There is no price at present, please contact us.
More Information
| Brand | NMB |
|---|---|
| Model Number | 09225VA-24Q-EA-00 |
| Type | DC Axial Fans |
| Series | 09225VA/3610VL |
| Frame Size | 92x25mm |
| Bearing Type | Ball |
| Voltage | 24 V |
| Current | 0.38 A |
| Speed | 5600 RPM |
| Power | 9.12 W |
| Air Flow | 96.4 CFM |
| Static Pressure | 0.6 InH?O |
| Noise | 51 dBA |
| Expected life | 60oC 40,000 Hours |
| Terminals | UL3385, AWG26, +Red, -Black |
| Operating Temperature | -10oC~+70oC |
| Housing Material | Casing : Plastic (Black)UL94V-0；Impeller : Plastic (Black)UL94V-0 |
