NMB Fans 08038DA-12T-E6E-0
NMB 08038DA-12T-E6E-0 80x38mm 08038DA （E-Type Three Phase） Series DC Axial Fans
- SKU
- NBF-1734
There is no price at present, please contact us.
More Information
| Brand | NMB |
|---|---|
| Model Number | 08038DA-12T-E6E-0 |
| Type | DC Axial Fans |
| Series | 08038DA （E-Type Three Phase） |
| Frame Size | 80x38mm |
| Bearing Type | Ball |
| Voltage | 12 V |
| Current | 5.1 A |
| Speed | 17000 RPM |
| Power | 61.2 W |
| Air Flow | 137.7 CFM |
| Static Pressure | 5.48 InH?O |
| Noise | 76.5 dBA |
| Expected life | 70oC 44,000 Hours |
| Terminals | UL3385 or UL10368 AWG20, +Red, -Black |
| Operating Temperature | -10oC~+60oC |
| Housing Material | Casing : Plastic (Black)UL94V-0；Impeller : Plastic (Black)UL94V-0 |
