NMB Fans 06025MA-24N-EA-00
NMB 06025MA-24N-EA-00 60x25mm 06025MA Series DC Axial Fans
- SKU
- NBF-1705
There is no price at present, please contact us.
More Information
| Brand | NMB |
|---|---|
| Model Number | 06025MA-24N-EA-00 |
| Type | DC Axial Fans |
| Series | 06025MA |
| Frame Size | 60x25mm |
| Bearing Type | Ball |
| Voltage | 24 V |
| Current | 0.1 A |
| Speed | 4900 RPM |
| Power | 2.4 W |
| Air Flow | 23.3 CFM |
| Static Pressure | 0.25 InH?O |
| Noise | 35 dBA |
| Expected life | 25oC 100,000 Hours |
| Terminals | UL1007, AWG24, +Red, -Black |
| Operating Temperature | -10oC~+70oC |
| Housing Material | Casing : Plastic (Black)UL94V-0；Impeller : Plastic (Black)UL94V-0 |
